The RITAR HR12-80W (12V80W) is an HR (High Rate) Series Valve Regulated Lead-Acid (VRLA) battery designed for heavy-load discharge applications. It features an 8-year design life in float service and uses strong grids, thick plates, and specially designed active materials to provide low internal resistance, low self-discharge, high power output, and extended service life.
Description
Key Features
- High-Rate Discharge Technology — optimized for heavy-load discharge applications.
- 30% More Power Output — compared with the standard series.
- 8-Year Design Life — specified for float service.
- 12V / 80W High-Rate Battery — designed for high-power standby applications.
- High Discharge Current — up to 200A for 5 seconds.
- 900A Short-Circuit Current — high-current capability for demanding applications.
- Very Low Internal Resistance — ≤12.0 mΩ at full charge and 25°C.
- Low Self-Discharge — less than 3% per month at 25°C.
- Wide Operating Temperature — discharge from -20°C to 60°C.
- Maximum Charging Current — 6.0A.
- Strong Grid & Thick Plate Construction — supports high power output and service life.
- ABS Container — UL94-HB standard, with UL94-V0 optional.
- F13-BP (M5) Terminal — default terminal configuration.
- Critical Power Applications — suitable for data centers, UPS, EPS and other high-power standby
