The RITAR HR12-104W (12V104W) is an HR (High Rate) Series Valve Regulated Lead-Acid (VRLA) battery designed for heavy-load discharge applications. It provides an 8-year design life in float service.
The HR Series uses strong grids, thick plates and specially designed active materials to achieve low internal resistance, low self-discharge, high power output and longer service life. According to the datasheet, the HR Series provides 30% more power output than the standard series, making the HR12-104W suitable for high-power standby applications such as data centers, UPS and EPS systems.
Description
Key Features
- High-Rate Discharge Technology — engineered for heavy-load discharge applications.
- 30% More Power Output — compared with the standard series.
- 8-Year Design Life — specified for float service.
- 12V / 104W High-Rate Battery — designed for high-power standby applications.
- High Discharge Current — maximum 260A for 5 seconds.
- 980A Short-Circuit Current — high-current capability.
- Very Low Internal Resistance — ≤9.0 mΩ at full charge and 25°C.
- Low Self-Discharge — less than 3% per month at 25°C.
- Wide Operating Temperature Range — discharge -20°C to 60°C.
- Maximum Charging Current — 7.8A.
- Strong Grid & Thick Plate Construction — supports high-rate performance and service life.
- ABS Container — UL94-HB standard, with UL94-V0 optional.
- F13-BP (M5) Terminal — default terminal configuration.
- Critical Power Applications — suitable for data centers, UPS, EPS and other high-power standby systems.
- Temperature Compensation — charging compensation specified for temperature variation.
- Quality Management Certifications — the datasheet displays ISO 9001, ISO 14001 and ISO 45001 certifications.
