The RITAR HR12-36W (12V36W) is an HR (High Rate) Series Valve Regulated Lead-Acid (VRLA) battery designed for heavy-load discharge applications. It has an 8-year design life in float service and uses strong grids, thick plates, and specially designed active materials to provide lower internal resistance, lower self-discharge, high power output, and longer service life.
Description
Key Features
- High-Rate Discharge Technology — designed specifically for heavy-load discharge applications.
- 30% More Power Output — compared with the standard RITAR series.
- 8-Year Design Life — specified for float service.
- Strong Grids & Thick Plates — construction designed for high power output and longer service life.
- Low Internal Resistance — ≤22.0 mΩ at full charge and 25°C.
- High Discharge Current — maximum 90A for 5 seconds.
- High Short-Circuit Current — 450A.
- Low Self-Discharge — less than 3% per month at 25°C.
- Wide Operating Temperature Range — discharge -20°C to 60°C.
- Maintenance-Free VRLA Construction — valve-regulated lead-acid technology.
- ABS Container — UL94-HB standard, with UL94-V0 optional.
- F2 Terminal — default terminal configuration.
- High-Power Standby Applications — suitable for data centers, UPS and EPS systems
